MAG 300H EVO III Head Specifications
Power Output (RMS) 307W
Power Requirement 230 /115v
Speaker Outputs 2 x Jack Outputs
Frequency Response -3dB at 17Hz and 30KHz
High Instrument Input Impedance 3.9MOhms / Input range 150mV - 20V p-p
Low Instrument Input Impedance 10KOhms / Input range 300mV - 40V p-p
Line Input Impedance 22k Ohms / Input level 0dBu nominal
DI Output 600 Ohms balanced / Level -20dBu nominal
Tuner Output Impedance 22k Ohms / Level 0dBu nominal
Impedance Minimum 4 Ohms
Signal to noise Better than 80dB (EQ flat)
EQ Bass +/-15dB @ 100Hz Lo Mid +/-15dB @ 220Hz Middle +/-15dB @ 660Hz Hi Mid +/-15dB @ 1.6kHz Treble +/-15dB @ 7kHz shelving Deep +
Effects Send Impedance 22k Ohms / Level 0dBu nominal
Effects Return Impedance 22k Ohms / Level 0dBu nominal
Distortion Less than 0.5% THD
H x W x D (mm) 90 x 463 x 267
Weight (kg) 8.5

Cover su misura inclusa.
